Product Details:
Place of Origin: MADE IN CHINA
Brand Name: MAZS
Certification: CE,ISO
Model Number: MAΦ205×900/Φ650×850
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: USD
Packaging Details: Machine will be fixed inside container by steel wire(Export standard sea package)
Delivery Time: 120-150 working days
Payment Terms: T/T or 100% at sight LC or 30% deposit and 70% before shipping.
Supply Ability: 20sets per year

High Speed Four Stand 800mm Continuous Cold Rolling Mill line used for make pipe Q195,Q215,Q235

Description
Description Of Goods: Four Stands Cold Rolling Mill Machine With Full Mechanical Press Down Control System For Q195,Q215,Q235 With High Speed Work Rollers (mm): Φ205
Roller Length (mm): 850 Input Thickness (mm): 3
Finished Thickness (mm): 0.25 Width: 800mm
Voltage: 380V 50Hz 3phases Or Order By The User Color: As Our Standard Or Order By User
High Light:

5500KN Continuous Cold Rolling Mill

,

800mm Continuous Cold Rolling Mill

,

High Speed cold rolling machine

1. Description of goods:

Four stands cold rolling mill machine with Full mechanical press down control system for Q195,Q215,Q235 with high speed



2. Introduction:
Due to different numbers of rollers, the metal coil cold rolling mill is divided into 2 Hi, 4 Hi, 6 Hi, and 12 Hi AGC.
The 4-Hi cold rolling mill, one of metal coil cold rolling mill, is made from good quality raw material. A four-high cold rolling mill has four rolls, two small and two large. The two small rolls are work rolls in contact with metal coil, and the two large rolls are backup rolls which contact the back side of the small work rolls. At the same time, we are upgrading with the latest technological equipments when producing this cold rolling mill.



3. Features:

1. The second type of cold rolling mill controls rolling speed and its tension.
2. The stable rolling is ensured.
3. This machinery great guarantee the safety.
Hydraulic AGC System
Functions: AGC (hydraulic control of press-down seam), AFC (constant rolling force control), pre-control of thickness gauge, monitoring, etc
Precision:
Stable rolling: 0.3mm ±4.5μm; 0.5-0.8mm ±7μm
Speed-up and speed-down rolling: 2%h≤±10μm



4. Techncial parameter:

Type Φ190/Φ535×600 Φ180/Φ650×850 Φ205×900/Φ650×850 Φ480/Φ1150×1380
Work roller (mm) Φ190 Φ180 Φ205 Φ480
Roller length (mm) 600 850 850 1380
Input thickness (mm) 3 3 3 3
Output thickness (mm) 0.5 0.4 0.25 0.3
Width(mm) 500 750 800 1000
Rolling force 4000KN 5000KN 5500KN 800T
Rolling speed (m/min) 150 150 210 120
Main motor (KW) 450 630 630 1200
Press-down motor 30 44 44 60



High Speed Four Stand 800mm Continuous Cold Rolling Mill line used for make pipe Q195,Q215,Q235 0High Speed Four Stand 800mm Continuous Cold Rolling Mill line used for make pipe Q195,Q215,Q235 1
