Product Details:
|
| Product Name: | Steel Coil Cutting Machine Cut To Length Steel Coil Shearing Line | Material: | CR, HR Carbon Steel Coils, GI, PPGI Steel Plates. |
|---|---|---|---|
| Voltage:: | 380V 50Hz 3phases Or Order By The User | Quality Guarantee: | One Year After Shipping |
| Machine Color: | It’s Order By The User Or By Our Standard | After Service: | Avalible On Any Local China Working Time |
| Cutting Speed: | (0~40) M/min, Adjustable | Color: | As Our Standard Or Order By User |
| High Light: | 1.0-6.0mm Steel Cut To Length Line,6x1600mm Steel Cut To Length Line,CE metal cut to length machine |
||
1. Products name:
Strip thickness: 1~6mm Middle thick Sheet cut to length equipment, model :MA-(1~6)×1600mm
2. Advantages & Characteristics for this coil CTL line:
High precision
Line speed can be up to 30m/min, 7-8pcs/min 2000mm Length sheets in average;
Leveling precision: ±1mm/㎡;
Sheet length precision: ±0.5mm/m;
Sheet diagonal length precision: ±0.5mm/m;
3. Main technical parameter:
| Model | Thickness | Length | Leveling speed | |
| MA-6 x 1600 | 1.0-6.0mm | 600-1600mm | adjustable | Max 40m/min |
| MA-8 x 1800 | 2.0-8.0mm | 1000-1800mm | adjustable | Max 30m/min |
| MA-10x 2000 | 3-10mm | 1000-2000mm | adjustable | Max 30m/min |
| Note: The data in the form just as reference according to general ranges, we always design and make each thick plate cut-to-length line (coil CTL line) according to each customer’s specific requirements, so each customer can buy his own well-content line from us. | ||||
