Product Details:
|
| Product Name: | Purlin Forming Machine | Thickness:: | 0.3-2.0mm |
|---|---|---|---|
| Speed: | 130m/min | Main Power: | 18.5KW |
| Control System: | PLC Panasonic | Drive: | By Motor And Gear Box |
| Voltage: | 380V 50Hz 3phases Or Order By The User | Color: | Customerization |
| Procession Precision: | Within 1.0mm | ||
| High Light: | Gear Box Drive Purlin Forming Machine,Automated Purlin Forming Machine,Purlin Forming Machine 15m/Min |
||
1. Composition of production line equipment
1. Hydraulic loading trolley
2. Hydraulic cantilever decoiler
3. Coil pressing and uncoiling device
4. Double roll pinch and plate shearing machine
5. Electric eye control looper table
6. Left and right positioning device
7. Slitting machine
8. Scrap collecting device (with wire arrangement function)
9. Electric eye control looper table
10. Separator device and damping device
11. Hydraulic recoiler
12. Unloading trolley
13. Hydraulic system
14. Electrical system
2. Technical Parameters:
a. Applicable materials: cold rolled, galvanized coil
b. Material quality: domestic standard steel or international standard steel
c. Material thickness: 0.3-3.0mm,
D. Material width: 500-1250 (Max)
E. Inner diameter of steel coil: φ508 φ610 (rubber band added by the manufacturer)
f. Outer diameter of steel coil: φ1600(Max)
g. Steel coil weight: 15T (Max)
H. Inner diameter of recoiling: φ508
i. Machine running speed: 130m/min
j. Diameter of slitting blade shaft: φ180 material: 40Cr
k. Longitudinal blade:ф180×ф320×10
l. Material of slitting blade: H13K
3. Specifications:
| Model | Thickness | Coil Weight | Finished slit | Max Slitting speed | |
| MA-1 x 600 | 0.2-1mm | 100-600mm | Max 8T | Min. 20mm | 50m/min |
| MA-2 x 1300 | 0.3-2mm | 300-1300mm | Max 15T | Min. 25mm | 80m/min |
| MA-3 x 1600 | 0.3-3mm | 500-1600mm | Max 20T | Min 25mm | 100m/min |
| MA-4 x 1600 | 0.4-4mm | 500-1600mm | Max 30T | Min 30mm | 80m/min |
| Note: The data in the form just as reference according to general ranges, we always design and make each line according to each customer’s specific requirements, so each customer can buy his own well-content line from us. |
|||||
4. Packaging:
Machine will be fixed inside container by steel wire, in order to make sure it won’t move during transportation and avoid any kinds of damage of machine and container.
