Product Details:
|
| Product Name: | Steel Coil Slitting Line Used To Thickness 0.6~10mm For Cold Rolling Mill, Welded Pipe Mill, Roll Forming Machine, Etc | Thickness:: | (0.6-5) Mm |
|---|---|---|---|
| Strip Width: | 500~1500mm | Steel Slitter Inner Diameter Of Coils: | Φ508mm, Φ610mm, Φ760mm |
| Max.outer Diameter Of Coils: | Φ2000mm | Max.coil Weight: | 30000kg |
| Steel Slitter Shaft: | Φ250 X 1550mm | Material Of Disc Cutter: | 6CrW2Si, HRC55-58. |
| Ccolor: | As Our Standard Or Order By User | ||
| High Light: | 3KW down pipe forming machine,0.4-1.0mm down pipe forming machine,ISO downpipe roll forming machine |
||
1. Product name:
Steel coil slitting line used to thickness 0.6~10mm for cold rolling mill, welded pipe mill, roll forming machine, etc.
2. Introduction:
Capacity of middle thick steel coil slitting line is mainly used to slit steel coils of thickness 0.6~5 mm, 1~6 mm, 2-8mm or 3~10mm. And for steel coils with width: 600~1600 mm, 800~1800mm or 800~2000mm into narrower baby coils. This steel slitter is widely used for proving steel strip coils for cold rolling mill, welded pipe mill, roll forming machine, etc.
3.The detail specification of Steel Slitter as follows:
| Model | Thickness | Coil Weight | Finished slit | Max Slitting speed | |
| MA-5 x 1500 | 0.6-5mm | 500-1500mm | Max 30T | Min. 40mm | 80m/min |
| MA-6 x 1600 | 1-6mm | 600-1600mm | Max 30T | Min. 50mm | 70m/min |
| MA-8 x 1800 | 2-8mm | 600-1800mm | Max 35T | Min 50mm | 80m/min |
| MA-10 x 2000 | 3-10mm | 800-2000mm | Max 35T | Min 60mm | 60m/min |
| Note: The data in the form just as reference according to general ranges, we always design and make each steel slitting machine according to each customer’s specific requirements, so each customer can buy his own well-content line from us. | |||||
5.What service we can get from your company?
- VIP Service. Due to our standards, we manage to build long-lasting relationships with all our customers.
We are 24/7 online available for you to answer your questions and solve your problems.
6. Quality Inspection:
The machines of our company have many certificates like ISO 9001, CE, SGS, etc.
Before the shipping, we have a series of quality check system, includes 3 times of inspection for every production procedure. First inspection needs the workers to check and sign on the test report. Second inspection involves department leaders to check and sign on the test report. The Third inspection needs professional inspector to check and ensure the machines are qualified.
We also give 12 month warranty time to the customer.
